ZDBX-10
ZDBX-10 Wire Cutting, Stripping And Twisting Machine
Product Info
LATEST WIRE TWISTING TECHNOLOGY HAS BEEN BUILT INTO A COMPACT BODY SUITABLE FOR USE WITH ZDBX-7. ADJUESTMENT OF THE TWISTING FORCE , SWITCHING OF NORMAL(Z TWISTING) AND REVERSE ( S TWISTING ) AND ADJUESTMENT OF TWISTING START POSITION CAN BE MADE BY ONE-TOUCH COMMAND OPERATION . FUTHERMOER IT CAN SMOOTHLY CATCH UP WITH CHANGE OF WIRE THICKNESS AND/OR FEEDING SPEED BY THE COMPUTER CONTROL SYSTEM . IT IS A TRULY SPEEDY , QUIET AND PRECISE TWISTING UNIT .
Product Description
MODEL: ZDBX-10
MEASUREMENT: W430×D360×H268mm
WEIGHT: 39kg
POWER SUPPLY: AC 220V
POWER CONSUMPTION: 300W
STRIPPING LENGTH: 0.1-- 30 mm
CUTTING LENGTH: 0.1-99999 mm
CUTTING TOLERANCES:(0.2±0.002 L) mm
WIRE TYPE: PVC, Teflon, Glass Wire
WIRE SIZE: AWG#18-AWG30
TWISTING LENGTH:3--18mm
PROCESSING CAPACITY: L=100mm, 135pcs/min
