HY-40
Semi-Automatic Mute Terminal Machine CT-40
Product features
•Accurate: Closed height can be adjusted continuously and the accuracy can reach to 0.03mm.
•Fast: Match to various molds, the replacement is easier and faster.
•Stable: The transmission structure is simple and the running system is stable and reliable.
•Save: Only work in the crimping moment, the power is saved greatly.
•Quiet: Low noise design, suitable for homework.
•Safe: Unique overload protection to ensure safe operation.
Technical parameters
Type: CT-4020 4040 (itinerary 40)
Type: CT-3020 3040 (itinerary 30)
Size: W360xD300xH890mm
Size: W400xD350xH950mm
Closed height: 121.7mm/135.8mm
Electronic source: AC 220V/50HZ
Itinerary: 30mm/40mm
Pressure: 2T、4T
Power：750W、1500W
Weight：60/80 KG
